Which is better? "BETWEEN" vs "<=" and >"="

This was a recent topic on the DB2-L mailing list so I thought I'd weigh in with my two cents worth on the topic.

As with most DB2 (and, indeed, IT) issues, the correct answer is "it depends!" Let's dig a bit deeper to explain what I mean.

From a maintainability perspective, BETWEEN is probably better. The BETWEEN predicate is easier to understand and code than the equivalent combination of the less than or equal to predicate (<=) and the greater than or equal to predicate (>=). In past releases, in many cases it was more efficient, too. But today the Optimizer recognizes the two formulations as equivalent and there usually is no performance benefit one way or the other. Performance reasons aside, one BETWEEN predicate is easier to understand and maintain than multiple <= and >= predicates. For this reason, I tend to favor using BETWEEN.

But not always. Consider the scenario of comparing a host variable to two columns. Usually BETWEEN is used to compare one column to two values, here shown using host variables:

WHERE COLUMN1 BETWEEN :HOST-VAR1 AND :HOST-VAR2

However, it is possible to use BETWEEN to compare one value to two columns, as shown:

WHERE :HOST-VAR BETWEEN COLUMN1 AND COLUMN2

This statement should be changed to

WHERE :HOST_VAR >= COLUMN1 and :HOST-VAR <= COLUMN2

The reason for this exception is that a BETWEEN formulation comparing a host variable to two columns is a Stage 2 predicate, whereas the preferred formulation is Stage 1. And we all know that Stage 1 outperforms Stage 2, right?

Remember too, that SQL is flexible and often the same results can be achieved using different SQL formulations. Sometimes one SQL statement will dramatically outperform a functionally equivalent SQL statement just because it is indexable and the other is not. For example, consider this SQL statement

SELECT EMPNO, FIRSTNME, MIDINIT, LASTNAME
FROM EMP
WHERE MIDINIT NOT BETWEEN 'A' AND 'G';

It is not indexable because it uses the NOT BETWEEN predicate. However, if we understand the data in the table and the desired results, perhaps we can reformulate the SQL to use indexable predicates, such as

SELECT EMPNO, FIRSTNME, MIDINIT, LASTNAME
FROM EMP
WHERE MIDINIT >= 'H';

Or we could code MIDINIT BETWEEN 'H' AND 'Z' in place of MIDINIT >= 'H'. Of course, for either of these solutions to work correctly we would need to know that MIDINIT never contained values that collate lower than the value 'A'.

So, as usual, there is no one size fits all answer to the question!

Quick Thoughts on DB2 Performance

Database performance problems are not caused by magic. Indeed, all performance problems are always caused by change. That statement flies in the face of what I normally say, which is “Almost never say always or never”… but in this case, it is true.

Think about it for a moment. If everything remains stable and unchanging in your environment, then why would performance vary? That’s right, it wouldn’t.

Something tangible must change before a performance problem can be experienced. The challenge of performance tuning is to find the source of the change, gauge its impact, and formulate a solution.

Change can take many forms, including the following:

• Physical changes to the environment, such as a new CPU, new disk devices, or different tape drives.

• Changes to system software, such as a new release of a product (for example, WebSphere, CICS, or even z/OS), the alteration of a product (for example, the addition of more or fewer CICS regions or an IMS SYSGEN), or a new product (for example, implementation of DFHSM). Also included is the installation of a new release or version of DB2, which can result in changes in access paths as well as utilization of new features.

• Changes to the DB2 engine from maintenance releases and PTFs, which can change the optimizer (and sometimes introduce other new functionality).

• Changes in system capacity. More or fewer jobs could be executing concurrently when the performance problem occurs. Or additional users may be banging away at your transactions.

• Environmental changes, such as the implementation of client/server programs, the adoption of SOA, or other new technologies.

• Database changes. This involves changes to any DB2 object, and ranges from adding a new column or an index to dropping and re-creating an object.

• Changes to the application development methodology, such as usage of check constraints instead of application logic or the use of stored procedures.

• Changes to application code, both SQL and host language code (COBOL, C, Java, etc.).


Although the majority of your performance problems are likely to be application-oriented, you must be prepared to explore any and all of these other areas when application tuning has little effect.

My advice is to be sure that you institute strict change control tracking across all areas of your IT infrastructure. That way, whenever you experience a performance problem, you will be able to track what has changed recently, along with who changed it and why. This is important because every DBA knows what the answer to the question “What changed?” will be… right?

It is always “nothing!”

And that cannot be true. Oh, it does not mean that the person answering is lying. He or she may not have changed anything. And it is not necessarily reasonable to expect an application developer to know what all could have changed…especially when what can impact DB2 performance spans so many areas of the IT infrastructure.

So do yourself… and your company a favor: be sure that you meticulously track each and every change to any aspect of your systems. Then – and this is where many shops break down – make sure that you have methods of tying all of the change information together in such a way that it can be queried and examined in the face of a performance problem.

Only then can you reasonably expect your DBAs rapidly to be able to track down and remedy DB2 performance problems… because only then will they have the pertinent information at their disposal.

Dynamic SQL Causing Lock Escalation?

Lock escalation is the promotion of a lock from a row, page or LOB lock to a table space lock because the number of page locks that are concurrently held on a given resource exceeds a preset limit.

But lock escalation can cause problems. Yes, when fewer locks are taken, CPU cost and memory usage can be reduced. On the other hand, escalating the size of a lock causes more resources to be locked... and that impacts concurrency with the most likely result being applications experiencing lock timeouts or deadlocks.

When lock escalation occurs, DB2 writes messages to the system log. So when complaints inevitably arrive about failing transactions you can look for the appropriate lock escalation message indicating that it could be the culprit.

But such simple steps are typically not sufficient to track down the root cause and take corrective actions. You need to be able to determine what SQL statement in what program and under what circumstances is causing the escalation. Doing so involves tracing and using performance monitoring tools.

For those interested in this topic, (indeed, the primary purpose of this blog post) you should seek out the IBM TechDoc titled Identifying the dynamic SQL statement which is causing a
lock escalation in DB2 for z/OS. For those who don't know what a TechDoc is, don't worry, it isn't that complicated. It is basically a published piece of technical documentation that isn't part of a larger manual or IBM RedBook. They can be short papers, product flashes, presentations, etc.

This particular TechDoc details a methodology for identifying dynamic SQL statements involved in a lock escalation. It describes which traces to start, and which jobs to run to analyze the collected traces. It also explains how to analyze the trace report to find the problematic SQL statement.

You can search all of IBM's TechDocs by following this link.

Happy reading!

Approaches to Access Path Management

BIND and REBIND are important components in assuring efficient DB2 applications. Because the
BIND/REBIND process determines exactly how your DB2 data is accessed, it is important that you develop an appropriate strategy for when and how to REBIND your programs.

There are several common REBIND approaches taken by DB2 users. By far, the best approach is to REBIND your applications over time as your data and systems change. This approach involves some form of regular maintenance that keeps DB2 statistics up to date and formulates new access paths as data volumes and patterns change.

Other approaches include REBINDing only when a new version of DB2 is installed, or perhaps more ambitious, whenever new PTFs are applied to DB2. Another approach is to REBIND automatically after a regular period of time (days, weeks, months, etc.). This approach can work if the period of time is wisely chosen based on the application data – but it still can pose administrative issues.

The final approach can be summarized as “if it ain’t broke don’t fix it!” This is the worst of the several approaches discussed here. The biggest problem with this approach is that you are penalizing every program in your subsystem for fear that a program or two may have a degraded access path. This results in potentially many programs having sub-optimal performance because the optimizer never gets a chance to create better access paths as the data changes.

Of course, the possibility of degraded performance is real – and that is why this approach has been adopted at some sites. The problem is being able to find which statements have degraded. In an ideal world we would be to be able to review the access path changes beforehand to determine if they are better or worse. But DB2 itself does not provide any systematic method of administering access paths that way. There are third party tools that can help you achieve this though.

Anyway, let’s go back to the best approach again, and that is to REBIND on a regular basis as your data changes. This approach has become known as the three Rs. To implement this approach you:

1. Regularly reorganize the data to ensure that it is optimally structured.
2. Follow that with RUNSTATS to be sure that the reorganized state of the data is reflected in the DB2 Catalog.
3. And follow that with a REBIND for all the application programs that access the data structures impacted by the REORG and RUNSTATS.

At any rate, your goal should be to keep your access paths up-to-date with the current state of your data. Failing to do this means that DB2 is accessing data based upon false assumptions. DB2 is unlikely to make the same access path choice as your data grows – and as patterns within the data change.

By REBINDing you can generally improve the overall performance of your applications because the access paths will be better designed based on an accurate view of the data. Additionally, as DB2 changes are introduced (PTFs, new version/release) optimizer improvements and new access techniques can be incorporated into the access paths. That is, if you never REBIND, not only are you forgoing better access paths due to data changes but you are also forgoing better access paths due to changes to DB2 itself.

Adopting the Three R’s approach can pose additional questions. For example, when should you reorganize? In order to properly determine when a REORG is needed you’ll have to look at statistics. This means looking at either RUNSTATS or Real-Time Statistics (RTS). So, we need to add another R – in other words:

1. RUNSTATS or better yet, RTS
2. REORG
3. RUNSTATS
4. REBIND

Now it is true that some folks don’t rely on statistics to schedule a REORG. Instead, they just build the JCL to REORG their database objects when they create the object. So they create a table space then build the REORG job and schedule it to run monthly, or quarterly, or on some regular basis. This is better than no REORG at all, but it is probably not the best approach because you are most likely either reorganizing too soon (in which case you waste the CPU cycles to do the REORG) or you are reorganizing too late (in which case performance is suffering for a period of time before the REORG runs). Better to base your REORGs off of statistics and thresholds using either RUNSTATS or RTS.

Without accurate statistics there is little hope that the optimizer will formulate the best access path to retrieve your data. If the optimizer doesn’t have accurate information on the size, organization, and particulars of your data then it will be creating access paths based on either default or inaccurate statistics. Incorrect statistics will cause bad choices to be made – such as choosing a merge-scan join when a nested loop join would be better, or failure to invoke sequential prefetch, or using the wrong index – or no index at all. And the problem of inaccurate statistics is pervasive.

There are shops out there that never, or rarely, run RUNSTATS to gather up-to-date statistics. Make sure yours is not one of those shops!

When should you run RUNSTATS? One answer is “As frequently as possible based on how often your data changes.” To do this you will need to know a thing or two about your data growth patterns: what is its make-up, how is it used, how fast does it grow, and how often does it change? These patterns will differ for every table space in your system.

Next we need to decide when to REBIND? The best answer for this is when statistics have changed significantly enough to change access paths. When we know that data has significantly changed it makes sense to REBIND after the RUNSTATS completes. But the trick is determining exactly when we have a “significant” change in our data. Without an automated method of comparing and contrasting statistics (or even better yet, access paths) coming up with an answer in a manual way can be time-consuming and error-prone – especially if we have thousands of DB2 programs to manage.

As we REBIND, we always must be on alert for rogue access paths. A rogue access path is created when the optimizer formulates a new access path that performs worse than the previous access path. This can happen for a variety of reasons. Of course, number one is that the optimizer, though good, is not perfect. So mistakes can happen. Other factors can cause degraded access paths, too. The access paths for volatile tables depend on when you run the RUNSTATS. Volatile tables are those that start out empty, get rows added to them during processing, and are emptied out at the end of the day. And, of course, if the catalog or statistics are not accurate we can get problems, too.

So adopting the Four R’s approach implies that you will have to develop a methodology for reviewing your access paths and taking care of any “potential” problem access paths. Indeed, the Four R’s becomes the Five R’s as we add a step to review the access paths after REBINDing to make sure that there are no rogue access paths:

1. Start RTS (or a RUNSTATS) to determine when to REORG.
2. Reorganize the table spaces (and/or indexes)
3. After reorganizing, run RUNSTATS again,
4. Follow that with the REBINDs.
5. Then we need that fifth R – which is to Review the access paths generated by the REBIND.

The review is of utmost importance because the optimizer can make mistakes. And, of course, so can you. But your users will not call you when performance is better (or the same). They only ring you up when performance gets worse. As such, proactive shops will put best practices in place to test REBIND results comparing the before and after impact of the optimizer’s choices.

Approaches to Access Path Management... or The Five R's

BIND and REBIND are important components in assuring efficient DB2 applications. Because the BIND/REBIND process determines exactly how your DB2 data is accessed it is important that you develop an appropriate strategy for when and how to REBIND your programs.

There are several common REBIND approaches taken by DB2 users. By far, the best approach is to REBIND your applications over time as the data changes. This approach involves some form of regular maintenance that keeps DB2 statistics up to date (or better yet, uses Real Time Statistics) and formulates new access paths as data volumes and patterns change.

Other approaches include REBINDing only when a new version of DB2 is installed, or perhaps more ambitious, whenever new PTFs are applied to DB2. Another approach is to REBIND automatically after a regular period of time (days, weeks, months, etc.). This approach can work if the period of time is wisely chosen based on the application data – but it still can pose administrative issues.

Another (unfortunately) popular approach can be summarized as “if it ain’t broke don’t fix it!” This is the worst of the several approaches discussed here. The biggest problem with this approach is that you are penalizing every program in your subsystem for fear that a program or two may have a degraded access path. This results in potentially many programs having sub-optimal performance because the optimizer never gets a chance to create better access paths as the data changes.

Of course, the possibility of degraded performance is real – and that is why this approach has been adopted at some sites. The problem is being able to find which statements have degraded. In an ideal world we would be to be able to review the access path changes beforehand to determine if they are better or worse. But DB2 itself does not provide any systematic method of administering access paths that way. There are third party tools that can help you achieve this though.

Anyway, let’s go back to the best approach again, and that is to REBIND on a regular basis as your data changes. This approach has become known as the three Rs. To implement this approach you:

1. Regularly REORGanize the data to ensure that it is optimally structured.
2. Follow that with RUNSTATS to be sure that the reorganized state of the data is reflected in the DB2 Catalog.
3. And follow that with a REBIND for all the application programs that access the data structures impacted by the REORG and RUNSTATS.

At any rate, your goal should be to keep your access paths up-to-date with the current state of your data. Failing to do this means that DB2 is accessing data based upon false assumptions. DB2 is unlikely to make the same access path choice as your data grows – and as patterns within the data change.

By REBINDing you can generally improve the overall performance of your applications because the access paths will be better designed based on an accurate view of the data. Additionally, as DB2 changes are introduced (PTFs, new version/release) optimizer improvements and new access techniques can be incorporated into the access paths. That is, if you never REBIND, not only are you forgoing better access paths due to data changes but you are also forgoing better access paths due to changes to DB2 itself.

Adopting the Three R’s approach can pose additional questions. For example, when should you reorganize? In order to properly determine when a REORG is needed you’ll have to look at statistics. This means looking at either RUNSTATS or RTS. So, perhaps it should be at least 4 R’s – in other words:

1. RUNSTATS or RTS
2. REORG
3. RUNSTATS
4. REBIND

Now it is true that some folks don’t rely on statistics to schedule a REORG. Instead, they just build the JCL to REORG their database objects when they create the object. So they create a table space then build the REORG job and schedule it to run monthly, or quarterly, or on some regular basis. This is better than no REORG at all, but it is probably not the best approach because you are most likely either reorganizing too soon (in which case you waste the CPU cycles to do the REORG) or you are reorganizing too late (in which case performance is suffering for a period of time before the REORG runs). Better to base your REORGs off of statistics and thresholds using either RUNSTATS or RTS.

Without accurate statistics there is little hope that the optimizer will formulate the best access path to retrieve your data. If the optimizer doesn’t have accurate information on the size, organization, and particulars of your data then it will be creating access paths based on either default or inaccurate statistics. Incorrect statistics will cause bad choices to be made – such as choosing a merge-scan join when a nested loop join would be better, or failure to invoke sequential prefetch, or using the wrong index – or no index at all. And the problem of inaccurate statistics is pervasive. There are shops out there that never, or rarely, run RUNSTATS to gather up-to-date statistics. Make sure yours is not one of those shops!

When should you run RUNSTATS? One answer is “As frequently as possible based on how often your data changes.” To do this you will need to know a thing or two about your data growth patterns: what is its make-up, how is it used, how fast does it grow, and how often does it change? These patterns will differ for every table space in your system.

Next we need to decide when to REBIND? The best answer for this is when statistics have changed significantly enough to change access paths. When we know that data has significantly changed it makes sense to REBIND after the RUNSTATS completes. But the trick is determining exactly when we have a “significant” change in our data. Without an automated method of comparing and contrasting statistics (or even better yet, access paths) coming up with an answer in a manual way can be time-consuming and error-prone – especially if we have thousands of DB2 programs to manage.

As we REBIND, we always must be on alert for rogue access paths. A rogue access path is created when the optimizer formulates a new access path that performs worse than the previous access path. This can happen for a variety of reasons. Of course, number one is that the optimizer, though good, is not perfect. So mistakes can happen. Other factors can cause degraded access paths, too. The access paths for volatile tables depend on when you run the RUNSTATS. Volatile tables are those that start out empty, get rows added to them during processing, and are emptied out at the end of the day. And, of course, if the catalog or statistics are not accurate we can get problems, too.

So adopting the Four R’s approach implies that you will have to develop a methodology for reviewing your access paths and taking care of any “potential” problem access paths. Indeed, the Four R’s becomes the Five R’s as we add a step to review the access paths after REBINDing to make sure that there are no rogue access paths:

1. Start with a RTS (or use RUNSTATS) to determine when to REORG.
2. REORGanize the table spaces (and indexes)
3. After reorganizing, run RUNSTATS (to ensure the DB2 Catalog is up-to-date)

4. Follow that with the REBINDs.
5. Then we need that fifth R – which is to review the access paths generated by the REBIND.

The review is of utmost importance because the optimizer can make mistakes. And, of course, so can you. But your users will not call you when performance is better (or the same). They only dial your numbers when performance gets worse. As such, proactive shops will put best practices in place to test REBIND results comparing the before and after impact of the optimizer’s choices. Again, there are tools that can help to automate this review process.

Basic DB2 Buffering and Memory Guidelines

One of the most important areas for tuning DB2 subsystem performance is memory usage. DB2 for z/OS uses memory for buffer pools, the EDM pool, RID pool and sort pools to cache data and structures in memory. The better memory is allocated to these structures, the better DB2 will perform.

When allocating DB2 buffer pools, keep these rules of thumb in mind:

Don't allocate everything to a single buffer pool (e.g., BP0); use a multiple buffer pool strategy.

Explicitly specify a buffer pool for every table space and index.

Isolate the DB2 Catalog in BP0; put user and application DB2 objects into other buffer pools.

Consider separating indexes from table spaces with each in their own dedicated buffer pools.

Consider isolating heavily hit data into its own buffer pool to better control performance.

Consider isolating sorts into a single buffer pool and tuning for mostly sequential access (e.g. BP7).

Consider separating DB2 objects into separate buffer pools that have been configured for sequential verses random access.

Forget about trying to follow a cookie-cutter approach to buffer pool management. Every shop must create and optimize a buffer pool strategy for its own data and application mix. DB2 offers the following buffer pool tuning "knobs" that can be used to configure virutal buffer pools to the type of processing they support:

DWQT –this value is the deferred write threshold; it is expressed as a percentage of the virtual buffer pool that might be occupied by unavailable pages. When this threshold is reached DB2 will start to schedule write I/Os to externalize data. The default is 50%, which is likely to be too high for most shops.

VDWQT – this value is the vertical deferred write threshold; it is basically the same as DWQT, but for individual data sets. The default is 10%, which once again is quite likely to be too high for many shops.

VPSEQT – this value is the sequential steal threshold; it is a expressed as a percentage of the virtual buffer pool that can be occupied by sequentially accessed pages. Tune buffer pools for sequential access such as scans and sorting by modifying VPSEQT to a larger value. The default is 80%.

VPPSEQT – this value is the sequential steal threshold for parallel operations; the default value is 50%.

VPXPSEQT – this value is assisting parallel sequential threshold; it is basically the VPPSEQT for opertaions from another DB2 subsystem in the data sharing group.

These parameters can be changed using the ALTER BUFFERPOOL command. Additionally, hiperpools can be created to back up DB2 virtual buffer pools with additional memory. DB2 provides several tuning knobs for hiperpools, too, including HPSIZE to adjust the size of hiperpools and HPSEQT to adjust the hiperpool sequential steal threshold.

With the advent of DB2 V8, we will have more memory at our disposal for DB2's use. This next version of DB2 will be able to surmount the limitation of 2GB real storage that was imposed due to S/390's 31-bit addressing. Theoretically, with 64-bit addressing DB2 could have up to 16 exabytes of virtual storage addressability to be used by a single DB2 address space. Now there is some room for growth!

In addition to buffer pools, DB2 uses memory for the EDM pool. The EDM pool is used for caching internal structures used by DB2 programs. This includes DBDs, SKCTs, CTs, SKPTs, and PTs. It also includes the authorization cache for plans and packages, as well as the cache for dynamic SQL mini-plans. As a general rule of thumb, shoot for an 80 percent hit rate with the EDM pool; this means that only one out every five times should a structure need to be loaded from disk into the EDM pool.

Finally, remember that buffer and EDM pool tuning are in-depth subjects that cannot be adequately covered in a high-level tip such as this. So, study those IBM DB2 manuals - and learn by doing. Additionally, there is much more to proper DB2 system performance tuning than memory tuning. Other system elements requiring attention include allied agent setup (CICS, TSO, etc.), network configuration, locking, logging, and Parallel Sysplex configuration and management for DB2 data-sharing shops.

Stages 3 and 4

All good DB2 developers and DBAs know about Stage 1 and Stage 2 predicates, right? But have you ever heard of Stage 3 and Stage 4 predicates? Well, you’re about to!

First of all, let’s do a quick review to catch those readers who don’t know what Stage 1 and 2 are. You may have heard about sargable and nonsargable, and if so, Stage 1 is sargable and Stage 2 is nonsargable. If not, don’t worry about those terms, they are obsolete.

A predicate that can be evaluated in the Data Manager (DM) component of DB2, that is at the earliest stage of query execution, is called a Stage 1 predcicate. Stage 2 predicates need to be passed up to the Relational Data System (RDS) to process. So Stage 1 predicates are more efficient than Stage 2 predicates because the Data Manager component of DB2 is at a level closer to the data than the Relational Data System. Stage 1 predicates, being evaluated earlier in the data retrieval process, avoid the overhead of passing data from component to component of DB2. For this reason, developers are encourage to use Stage 1 predicates rather than Stage 2 predicates to optimize performance.

What makes a predicate Stage 2 instead of Stage 1? Well, it is all in the type of predicate you code and how you write your SQL. There is a list of Stage 1 and Stage 2 predicates in Chapter 12 of the DB2 Performance and Tuning manual. (The same chart also tells you whether a predicates is indexable or not.) Whenever you move from one release of DB2 to another one of the first things you should do is consult this manual to see if any predicates have changed from Stage 2 to Stage 1… and you should make sure all of your developers have a copy of that chart taped to their cubicle wall!

OK, so what is all of this about Stage 3 and Stage 4, then? Well, it is a way of thinking about some bad SQL practices. Instead of coding a SQL predicate some programmers choose to bring all (or most) of the data into their program and then filter it using IF-THEN or CASE statements. You can think of these as Stage 3 predicates because it is one more place that the data must be passed to before it can be determined whether the data is needed.

Stage 4? That is when you use a black box (see the link for an explanation if you don't know what a black box is)... Instead of filtering the data in the DM or the RDS or even in your program, you have to work with another program altogether – the black box – to return the right data.

So just remember 1… 2… 3… 4… and that is the order of efficiency for those types of predicates. 1 is better than 2 is better than 3 is better than 4…

Don't Forget DISPLAY as a Part of Your DB2 Tuning Efforts

Although a DB2 performance monitor is probably the best solution for gathering information about your DB2 subsystems and databases, you can gain significant insight into “what is going on out there” using the simple DISPLAY command. The DISPLAY command can be used to return information about the status of DB2 data sharing groups, databases and table spaces, threads, stored procedures, user-defined functions, utilities, and traces; it can also monitor the Resource Limit Facility (RLF) and distributed data locations. Let’s take a quick tour of the useful information provided by the DISPLAY command.

Database Information

There are eight variations of the DISPLAY command that you can utilize, depending on the type of information you are looking for. Probably the most often-used variation of the DISPLAY command is the DATABASE option. By running the DISPLAY DATABASE command, you can gather information on DB2 databases and tablespaces. The output of the basic command will show the status of the objects specified along with any exception states that apply. For example:

-DISPLAY DATABASE(DBNAME)

Issuing this command will display details on the DBNAME database including information about the tablespaces and indexes in that database. So, with a simple command you can easily find all of the tablespaces and indexes within any database — pretty powerful stuff. But the status information for each space is useful, too. When a status other than RO or RW is encountered, the object is in an indeterminate state or is being processed by a DB2 utility. The possible statuses that DB2 can assign to a page set are detailed in the following table.

ARBDP	Index is in Advisory Rebuild Pending status; the index should be rebuilt to improve performance and allow the index to be used for index-only access again.
AREO*	The table space, index, or partition is in Advisory Reorg Pending status; the object should be reorganized to improve performance. This status is new as of DB2 V8.
ACHKP	The Auxiliary Check Pending status has been set for the base table space. An error exists in the LOB column of the base table space.
AREST	The table space, index space, or partition is in Advisory Restart Pending status. If back-out activity against the object is not already underway, either issue the RECOVER POSTPONED command or recycle the specifying LBACKOUT=AUTO.
AUXW	Either the base table space or the LOB table space is in the Auxiliary Warning status. This warning status indicates an error in the LOB column of the base table space or an invalid LOB in the LOB table space.
CHKP	The Check Pending status has been set for this table space or partition.
COPY	The Copy Pending flag has been set for this table space or partition.
DEFER	Deferred restart is required for the object.
GRECP	The table space, table space partition, index, index partition, or logical index partition is in the group buffer pool Recover Pending state.
ICOPY	The index is in Informational Copy Pending status.
INDBT	In-doubt processing is required for the object.
LPL	The table space, table space partition, index, index partition, or logical index partition has logical page errors.
LSTOP	The logical partition of a non-partitioning index is stopped.
PSRBD	The entire non-partitioning index space is in Page Set Rebuild Pending status.
OPENF	The table space, table space partition, index, index partition, or logical index partition had an open data set failure.
PSRCP	Indicates Page Set Recover Pending state for an index (non-partitioning indexes).
PSRBD	The non-partitioning index space is in a Page Set Rebuild Pending status.
RBDP	The physical or logical index partition is in the Rebuild Pending status.
RBDP*	The logical partition of a non-partitioning index is in the Rebuild Pending status, and the entire index is inaccessible to SQL applications. However, only the logical partition needs to be rebuilt.
RECP	The Recover Pending flag has been set for this table space, table space partition, index, index partition, or logical index partition.
REFP	The table space, index space, or index is in Refresh Pending status.
RELDP	The object has a release dependency.
REORP	The data partition is in a REORG Pending state.
REST	Restart processing has been initiated for the table space, table space partition, index, index partition, or logical index partition.
RESTP	The table space or index is in the Restart Pending status.
RO	The table space, tables pace partition, index, index partition, or logical index partition has been started for read-only processing.
RW	The table space, table space partition, index, index partition, or logical index partition has been started for read and write processing.
STOP	The table space, table space partition, index, index partition, or logical index partition has been stopped.
STOPE	The table space or index is stopped because of an invalid log RBA or LRSN in one of its pages.
STOPP	A stop is pending for the table space, table space partition, index, index partition, or logical index partition.
UT	The table space, table space partition, index, index partition, or logical index partition has been started for the execution of utilities only.
UTRO	The table space, table space partition, index, index partition, or logical index partition has been started for RW processing, but only RO processing is enabled because a utility is in progress for that object.
UTRW	The table space, table space partition, index, index partition, or logical index partition has been started for RW processing, and a utility is in progress for that object.
UTUT	The table space, table space partition, index, index partition, or logical index partition has been started for RW processing, but only UT processing is enabled because a utility is in progress for that object.
WEPR	Write error page range information.

Of course, there are many additional options that can be used in conjunction with the DISPLAY DATABASE command. The following options can be used to narrow down the amount of information displayed:

• USE displays what processes are using resources for the page sets in the database
• CLAIMERS displays the claims on the page sets in the database
• LOCKS displays the locks held on the page sets in the database
• LPL displays the logical page list entries
• WEPR displays the write error page range information.

Additionally, for partitioned page sets, you can specify which partition, or range of partitions, that you wish to display.

The OVERVIEW option can be specified to display each object in the database on its own line. This condenses the output of the command and makes it easier to view. The OVERVIEW keyword cannot be specified with any other keywords except SPACENAM, LIMIT, and AFTER.

Another tactic that can be used to control the amount of output generated by DISPLAY DATABASE is to use the LIMIT parameter. The default number of lines returned by the DISPLAY command is 50, but the LIMIT parameter can be used to set the maximum number of lines returned to any numeric value. For example:

-DISPLAY DATABASE(DBNAME) LIMIT(300)

Using the LIMIT parameter in this manner would increase the limit to 200 lines of output. To indicate no limit, you can replace the numeric limit with an asterisk (*).

Finally, you can choose to display only objects in restricted or advisory status using either the ADVISORY or RESTRICT key word.

Buffer Pool Information

The DISPLAY BUFFERPOOL command can be issued to display the current status and allocation information for each buffer pool. For example, consider the following:

---

-DISPLAY BUFFERPOOL (BP0)

DSNB401I ALLOCATED = 2000   TO BE DELETED = 0
             IN USE/UPDATED =       12

DSNB403I ALLOCATED = 100000   TO BE DELETED = 0
             BACKED BY ES   =    91402

DSNB404I VPSEQUENTIAL = 80  HPSEQUENTIAL = 80
            DEFERRED WRITE  = 50  VERTICAL DEFERRED WRT  = 10
            IOP SEQUENTIAL  = 50

DSNB405I HIPERSPACE NAMES - @001SSOP

DSN9022I DSNB1CMD '-DISPLAY BUFFERPOOL' NORMAL COMPLETION

---

We can see by reviewing these results that BP0 has been assigned 2,000 pages, all of which have been allocated. Furthermore, we see that it is backed by a hiperpool of 100,000 pages (so this is not a V8 subsystem, because hiperpools are no longer supported as of V8). The output also shows us the current settings for each of the sequential steal and deferred write thresholds.

For additional information on buffer pools you can specify the DETAIL parameter. Using DETAIL(INTERVAL) produces buffer pool usage information since the last execution of DISPLAY BUFFERPOOL. To report on buffer pool usage since the pool was activated, specify DETAIL(*). In each case, DB2 will return detailed information on buffer-pool usage such as the number of GETPAGEs, prefetch usage, and synchronous reads. The detailed data returned after executing this command can be used for rudimentary buffer pool tuning. For example, you can monitor the read efficiency of each buffer pool using the following formula:

(Total GETPAGEs) / [ (SEQUENTIAL PREFETCH) +
                    (DYNAMIC PREFETCH) +
                    (SYNCHRONOUS READ)
                  ]

A higher read efficiency value is better than a lower one because it indicates that pages, once read into the buffer pool, are used more frequently. Additionally, if buffer pool I/O is consistently high, you might consider adding pages to the buffer pool to handle more data.

Finally, you can gather even more information about your buffer pools using the LIST and LSTATS parameters. The LIST parameter lists the open table spaces and indexes within the specified buffer pools; the LSTATS parameter lists statistics for the table spaces and indexes reported by LIST. Statistical information is reset each time DISPLAY with LSTATS is issued, so the statistics are as of the last time LSTATS was issued.

Utility Execution Information

If you are charged with running (IBM) DB2 utilities, another useful command is DISPLAY UTILITY. Issuing a DISPLAY UTILITY command will cause DB2 to display the status of all active, stopped, or terminating utilities.

So, if you are in over the weekend running REORGs, issuing an occasional DISPLAY UTILITY allows you to keep up-to-date on the status of the job. By monitoring the current phase of the utility and matching this information with the utility phase information, you can determine the relative progress of the utility as it processes.

For the IBM COPY, REORG, and RUNSTATS utilities, the DISPLAY UTILITY command also can be used to monitor the progress of particular phases. The COUNT specified for each phase lists the number of pages that have been loaded, unloaded, copied, or read.

You also can check the progress of the CHECK, LOAD, RECOVER, and MERGE utilities using DISPLAY UTILITY. The number of rows, index entries, or pages, that have been processed are displayed by this command.

Log Information

You can use the DISPLAY LOG command to display information about the number of logs, their current capacity, and the setting of the LOGLOAD parameter. This information pertains to the active logs. DISPLAY ARCHIVE will show information about your archive logs.

Stored Procedure and UDF Information

If your organization uses stored procedures and/or user-defined functions (UDFs), the DISPLAY command once again comes in handy. You can use the DISPLAY PROCEDURE command to monitor stored procedure statistics. This command will return the following information:

• Whether the named procedure is currently started or stopped
• How many requests are currently executing
• The high-water mark for concurrently running requests
• How many requests are currently queued
• How many times a request has timed out
• The WLM environment in which the stored procedure executes

For UDFs, you can use the DISPLAY FUNCTION SPECIFIC command to monitor UDF statistics. This command displays one output line for each function that a DB2 application has accessed. It shows:

• Whether the named function is currently started or stopped, and why
• How many requests are currently executing
• The high-water mark for concurrently running requests
• How many requests are currently queued
• How many times a request has timed out
• The WLM environment in which the function executes

When displaying information about stored procedures and UDFs using the DISPLAY PROCEDURE and DISPLAY FUNCTION SPECIFIC commands, a status is returned indicating the state of the procedure or UDF. A procedure or UDF can be in one of four potential states:

1. STARTED - requests for the function can be processed
2. STOPQUE - requests are queued
3. STOPREJ - requests are rejected
4. STOPABN - requests are rejected because of abnormal termination

Log Information

There is a wealth of additional information that the DISPLAY command can uncover.

• For distributed environments, use DISPLAY DDF to show DDF configuration and status information, as well as statistical details on distributed connections and threads; use DISPLAY LOCATION to show information about distributed threads.
• For data sharing, you can use the DISPLAY GROUP command to display information about the data-sharing group (including the version of DB2 for each member); and DISPLAY GROUPBUFFERPOOL can be used to show information about the status of DB2 group buffer pools.
• If you use the Resource Limit Facility, the DISPLAY RLIMIT command can be used to show the status of the RLF, including the ID of the active Resource Limit Specification Table (RLST).
• To display active and in-doubt connections to DB2 for a specified connection or all connections, use the DISPLAY THREAD command.
• And finally, the DISPLAY TRACE command can be used to list your active trace types and classes along with the specified destinations for each.

Summary

The DB2 DISPLAY command is indeed a powerful, and simple tool that can be used to gather a wide variety of details about your DB2 subsystems and databases. Every DBA should know how to use DISPLAY and its many options to simplify their day-to-day duties and job tasks.

DB2 Performance Monitoring Overview

In today's blog entry we will discuss the basics monitoring and DB2 performance monitors.

The most common way to provide online DB2 performance monitoring capabilities is by online access to DB2 trace information in the MONITOR trace class. You generally specify OPX or OPn for the destination of the MONITOR trace. This way, you can place the trace records into a buffer that can be read using the IFI.

Some online DB2 performance monitors also provide direct access to DB2 performance data by reading the control blocks of the DB2 and application address spaces. This type of monitoring provides a "window" to up-to-the-minute performance statistics while DB2 is running. Such products can deliver in-depth performance monitoring without the excessive overhead of traces. Of course, they typically use a non-standard API into DB2, which could conceivable cause trouble.

Most online DB2 performance monitors provide a menu-driven interface accessible from TSO or VTAM. It enables online performance monitors to start and stop traces as needed based on the menu options chosen by the user. Consequently, you can reduce overhead and diminish the learning curve involved in understanding DB2 traces and their correspondence to performance reports.

Following are some typical uses of online performance monitors. Many online performance monitors can establish effective exception-based monitoring. When specified performance thresholds are reached, triggers can offer notification and take action. For example, you could set a ‘trigger’ when the number of lock suspensions for TXN2 is reached; when the ‘trigger’ is activated, a message is sent to the console and a batch report is generated to provide accounting detail information for the plan. You can set any number of ‘triggers’ for many thresholds.

Following are suggestions for setting thresholds:

• When a buffer pool threshold is reached (PREFETCH DISABLED, DEFERRED WRITE THRESHOLD, or DM CRITICAL THRESHOLD).

• For critical transactions, when predefined performance objectives are not met. For example, if TXN1 requires subsecond response time, set a trigger to notify a DBA when the transaction receives a class 1 accounting elapsed time exceeding 1 second by some percentage (10 percent; or even 25 percent, for example).

• Many types of thresholds can be established. Most online monitors support this capability. As such, you can customize the thresholds for the needs of your DB2 environment.

Online performance monitors can produce real-time EXPLAINs for long-running SQL statements. If an SQL statement is taking a significant amount of time to process, an analyst can display the SQL statement as it executes and dynamically issue an EXPLAIN for the statement. Even as the statement executes, an understanding of why it is taking so long to run can be achieved. This can be particularly useful for dynamic SQL because it is not pre-bound and therefore you which won’t have any access path information for it.

Online performance monitors can also reduce the burden of monitoring more than one DB2 subsystem. Multiple DB2 subsystems can be tied to a single online performance monitor to enable monitoring of distributed capabilities, multiple production DB2s, or test and production DB2 subsystems, all from a single session.

Most online performance monitors provide historical trending. These monitors track performance statistics and store them in DB2 tables or in VSAM files with a timestamp. They also provide the capability to query these stores of performance data to assist in the following:

• Analyzing recent history. Most SQL statements execute quickly, making difficult the job of capturing and displaying information about the SQL statement as it executes. However, you might not want to wait until the SMF data is available to run a batch report. Quick access to recent past-performance data in these external data stores provides a type of online monitoring that is as close to real time as is usually needed.

• Determining performance trends, such as a transaction steadily increasing in its CPU consumption or elapsed time.

• Performing capacity planning based on a snapshot of the recent performance of DB2 applications.

Some monitors also run when DB2 is down to provide access to the historical data accumulated by the monitor.

A final benefit of online DB2 performance monitors is their capability to interface with other z/OS monitors, for example IMS, CICS, MVS, and WebSphere monitors. This way, you can obtain a view of the entire spectrum of system performance.

Counting Down the DB2 Performance Top 40

The title of this blog posting is the title of one of my IDUG NA presentations this year. I'm blogging about it (briefly) today to solicit input and comments. I have my own ideas about the things I'll be covering in this presentation, but if you've got your own favorite performance "thing" that you think should be covered in a Top 40 presentation like this, please share it as a comment here on the blog.

Keep in mind that the presentation is a DB2 for z/OS presentation, so I won't be covering LUW or iSeries stuff.

Free Statistics Software for DB2 for z/OS

I'm sure you've heard that age old expression that there is no such thing as a free lunch, right? Well, sometimes even the old tried and true sayings can be wrong. No, I'm not going to tell you how to eat lunch for free, but you can get some helpful DB2 mainframe software for free!

NEON Enterprise Software continues to offer free software for checking the health of the statistics in your DB2 Catalog.

Statistics HealthCheck for DB2 z/OS enables you to quickly and effectively analyze and judge the quality of your DB2 Catalog statistics. Checking the health of your DB2 subsystem is especially important considering the heightened sensitivity of DB2 V8 and V9 to bad statistics.

The extensive rule system used by Statistics HealthCheck is based on best practice recommendations for maintaining good statistics. Using a violation system, Statistics HealthCheck pinpoints precisely those objects that could benefit from a RUNSTATS utility health check... or that otherwise require statistics housekeeping.

Statistics HealthCheck is particularly useful as a prerequisite to Bind ImpactExpert during a DB2 version migration. First, Statistics HealthCheck identifies the RUNSTATs you need. Then, Bind ImpactExpert provides REBIND insurance to further guarantee consistent and improved access paths.

With Statistics HealthCheck, you know exactly what is “wrong” with your statistics so that you can proactively correct any problems that might negatively affect DB2 subsystem performance.

And come on, it is free after all. What do you have to lose by downloading it and trying it on your DB2 subsystems today?

Database Performance and Row Size

Recently I was reading through some posts in a database-related newsgroup or mailing list (actually, right now I can't remember which one it was). The conversation I was reading was in response to a question like "Does the number of columns or size of the row matter in terms of performance?"

Actually, the question asked what kind of a performance impact might be expected if a query was issued against two similar tables. The first table had (say) 20 columns, and the second table had the same 20 columns, as well as 35 additional columns.

Well, most of the basic responses were similar. The consensus was that as long as the query was going against the same columns then performance should be about the same. I disagree. Here is why.

You also need to factor in the I/O requests that are required to return the data. The DBMS will perform I/O at the block (or page) level - this is so whether you return one row or millions of rows. For multi-row results, accessing data from the table with the wider row (more columns) will usually be less efficient. This is so because fewer rows will exist on each page (the row with 100 columns is smaller than the row with 150 columns so more rows can reside in a single, pre-sized block/page). The bigger the result set, the more pronounced the performance degradation can be (because more physical I/Os are required to retrieve the data).

Think about it this way. Is it faster to pull smaller peaches out of a basket than bigger peaches? That is about the same type of question and anybody can envision the process. Say you want 100 peaches. Small peaches fit 25 per basket; big peaches fit ten per basket. To get 100 small peaches you'd need to pull 4 baskets from the shelf. To get 100 big peaches you'd need to pull 10 baskets from the shelf. The second task will clearly take more time.

Of course, the exact performance difference is difficult to calculate - especially over an online forum and without knowledge of the specific DBMS being used. But there will, more than likely, be a performance effect on queries when you add columns to a table.
